Description
★ Detailed introduction
The machine body is made of high-density, high-rigidity castings, which have undergone high-temperature annealing and aging treatment;
The bed platform and saddle are reinforced with mountain-shaped ribs, ensuring short force flow lines and enhancing the rigidity of the machine body;
The contact length ratio between the spindle head and the column is appropriate, providing stable support for the spindle.
The heat of the spindle head is within a reasonable range, reducing the thermal elongation of the spindle and ensuring machining accuracy;
Imported grinding-grade pre-tensioned double nut screw rod is used to eliminate backlash.
The machine body is made of high-density, high-rigidity castings, which have undergone high-temperature annealing and aging treatment;
The bed platform and saddle are reinforced with mountain-shaped ribs, ensuring short force flow lines and enhancing the rigidity of the machine body;
The contact length ratio between the spindle head and the column is appropriate, providing stable support for the spindle.
The heat of the spindle head is within a reasonable range, reducing the thermal elongation of the spindle and ensuring machining accuracy;
Imported grinding-grade pre-tensioned double nut screw rod is used to eliminate backlash.
The entire machine adopts a PLC-controlled pressure-relief electric lubrication pump to provide uniform forced lubrication to all slide surfaces, ensuring precision and longevity.
Machine tool features
The ultra-wide column base design, with its widened base complemented by the box-type structure of the column, naturally forms an integrated, solid, and stable machining platform with the bed.
The bed castings are made of high-grade Mahanoy cast iron, which reduces twisting and deformation and enhances shock absorption capabilities. The cast billets undergo secondary tempering and aging treatment, and comprehensive inspections are conducted before and after processing to ensure flawlessness.
Finite element analysis ensures the optimized integrated design of the mechanical body;
The main spindle has 4-6 annular nozzles distributed around its circumference, providing optimal cooling effects for the cutting tool and workpiece, thereby enhancing the machining quality.
